Defender 7000 Bench Scale
OHAUS Defender 7000 Bench Scale
The OHAUS Defender 7000 Bench Scale combines an ABS plastic T71P indicator with painted steel bases and columns. Ideal for shipping and receiving, production, packaging and general commercial and industrial weighing applications, the Defender 7000 offers a multifunctional indicator with multiple weighing units, alpha-numeric keypad and software modes to meet the requirements of industrial and lab applications. With rugged construction, comprehensive yet intuitive software and multiple connectivity options, the Defender 7000 can meet the needs of demanding industrial operations. There are four lines in the 7000 series to meet your needs. One with a square platter, one with a rectangular platter and wash-down models that are square and rectangular.
- Defender 7000XW Xtreme Washdown, (“W” models- All Stainless Steel Bench Scale, IP66; NEMA 4X
- Defender 7000XW Xtreme Washdown (“H” models- Stainless Steel Bench Scale, IP67 Load Cell, Painted Column
- Defender 7000-Standard Models-304 stainless steel platform, IP67 load cell, painted body, ABS indicator
- Washdown for advanced applications (XW models)
- User- selectable language settings
- Advanced applications using data library and statistics
- Two scale operation plus multiple interface and relay options
- Quick display of results using large LCD with high-contrast white backlight
- Multiple weighing modes including Counting, Percent Weighing, Dynamic/Animal Weighing, Checkweighing, Display Hold, and Accumulation
- Options include DC relay control kit, AC relay control kit, RS485/422 and 2nd RS232 interfaces, sophisticated memory module
- Measurement Canada Certification
- NTEP Certified
- 1 year warranty
| Model # | Description | Capacity | Platter Size | Display | Unit of Measure | Battery | Dimensions | Shipping Weight |
|---|---|---|---|---|---|---|---|---|
| D71P10QR1 | Defender 7000 Std | 25 x 0.005 lb/10kg x 2 g | 12 x 12" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 12 x 3.7 x 23.2 x 12 x 16.7" | 37 Lbs |
| D71P15HR1 | Defender 7000 Std | 30 x 0.01 lb/15 kg x 5 g | 14 x 12" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 12 x 3.7 x 23.6 x 14 x 18.7" | 31 Lbs |
| D71P25QR1 | Defender 7000 Std | 50 lb x 0.01 lb 25 kg x 0.005 kg | 12 x 12" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 12 x 3.7 x 23.2 x 12 x 16.7" | 37 Lbs |
| D71P30HR1 | Defender 7000 Std | 60 lb x 0.02 lb 30 kg x 0.01 kg | 14 x 12" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 12 x 3.7 x 23.6 x 14 x 18.7" | 31 Lbs |
| D71P50QL2 | Defender 7000 Std | 100 lb x 0.02 lb 50 kg x 0.01 kg | 18 x 18" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 18 x 4.5 x 37 x 18 x 22.7" | 72 Lbs |
| D71P60HR1 | Defender 7000 Std | 150 lb x 0.05 lb 60 kg x 0.02 kg | 14 x 12" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 12 x 3.7 x 23.6 x 14 x 18.7" | 31 Lbs |
| D71P60HL2 | Defender 7000 Std | 150 lb x 0.05 lb 60 kg x 0.02 kg | 19.7 x 15.7" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 15.7 x 4.1 x 37 x 19.7 x 24.4" | 57 Lbs |
| D71P100HL2 | Defender 7000 Std | 250 lb x 0.1 lb 100 kg x 0.05 kg | 19.7 x 15.7" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 15.7 x 4.1 x 37 x 19.7 x 24.4" | 57 Lbs |
| D71P100QL2 | Defender 7000 Std | 250 lb x 0.05 lb 100 kg x 0.02 kg | 18 x 18" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 18 x 4.5 x 37 x 18 x 22.7" | 72 Lbs |
| D71P150HX2 | Defender 7000 Std | 300 lb x 0.1 lb 150 kg x 0.05 kg | 21.7 x 16.5" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 16.5 x 4.9 x 37 x 21.7 x 26.4 | 68 Lbs |
| D71P250QX2 | Defender 7000 Std | 500 x 0.1 lb/300 kg x 100 g | 24 x 24" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 24 x 5.4 x 37 x 24 x 28.7" | 98 Lbs |
| D71P300HX2 | Defender 7000 Std | 600 lb x 0.2 lb 300 kg x 0.1 kg | 21.7 x 16.5" | LCD | kg; g; lb; oz; lb:oz | AC/ DC | 16.5 x 4.9 x 37 x 21.7 x 26.4" | 68 Lbs |
| Model # | Description | Capacity | Platter Size | Display | Unit of Measure | Battery | Dimensions | Shipping Weight |
|---|---|---|---|---|---|---|---|---|
| D71XW10WR3 | Defender 7000XW Xtreme Washdown; All Stainless Steel Bench Scale; IP66; NEMA 4X | 25 lb x 0.005 lb 10 kg x 0.002 kg | 12 x 12" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 23.2 x 12 x 16.7 | 41 Lbs |
| D71XW25WR3 | Defender 7000XW Xtreme Washdown Stainless Steel Bench Scale; IP67 Load Cell; Painted Column | 50 lb x 0.01 lb 25 kg x 0.005 kg | 12 x 12" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 23.2 x 12 x 16.7 | 41 Lbs |
| D71XW50WL4 | Defender 7000XW Xtreme Washdown; All Stainless Steel Bench Scale; IP66; NEMA 4X | 100 lb x 0.02 lb 50 kg x 0.01 kg | 18 x 18" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 18 x 4.5 x 37 x 18 x 22.7" | 75 Lbs |
| D71XW100WL4 | Defender 7000XW Xtreme Washdown Stainless Steel Bench Scale; IP67 Load Cell; Painted Column | 250 lb x 0.05 lb 100 kg x 0.02 kg | 18 x 18" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 18 x 4.5 x 37 x 18 x 22.7 | 75 Lbs |
| D71XW250WX4 | Defender 7000XW Xtreme Washdown; All Stainless Steel Bench Scale; IP66; NEMA 4X | 500 lb x 0.10 lb 250 kg x 0.05 kg | 24 x 24" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 18 x 4.5 x 37 x 18 x 22.7 | 101 Lbs |
| D71XW15HR1 | Defender 7000XW Xtreme Washdown Stainless Steel Bench Scale; IP67 Load Cell; Painted Column | 30 x 0.01 lb/15 kg x 2 g | 12 x 12" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 23.2 x 12 x 16.7 | 41 lbs |
| D71XW30HR1 | Defender 7000XW Xtreme Washdown Stainless Steel Bench Scale; IP67 Load Cell; Painted Column | 60 x 0.02 lb/30 kg x 10 g | 14 x 12" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 23.6 x 14 x 18.7" | 34 Lbs |
| D71XW60HR1 | Defender 7000XW Xtreme Washdown; All Stainless Steel Bench Scale; IP66; NEMA 4X | 120 x 0.05 lb/60 kg x 20 g | 14 x 12" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 23.6 x 14 x 18.7" | 34 Lbs |
| D71XW60HL2 | Defender 7000XW Xtreme Washdown Stainless Steel Bench Scale; IP67 Load Cell; Painted Column | 120 x 0.05 lb/60 kg x 20 g | 19.7 x 15.7" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 15.7 x 4.1 x 37 x 19.7 x 24.4" | 60 Lbs |
| D71XW100HL2 | Defender 7000XW Xtreme Washdown Stainless Steel Bench Scale; IP67 Load Cell; Painted Column | 200 x 0.1 lb/100 kg x 50 g | 19.7 x 15.7" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 15.7 x 4.1 x 37 x 19.7 x 24.4" | 60 Lbs |
| D71XW150HX2 | Defender 7000XW Xtreme Washdow; All Stainless Steel Bench Scale; IP66; NEMA 4X | 300 x 0.1 lb/150 kg x 20 g | 21.7 x 16.5" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 29.5 x 30 x 9.1" | 71 Lbs |
| D71XW300HX2 | Defender 7000XW Xtreme Washdown Stainless Steel Bench Scale; IP67 Load Cell; Painted Column | 600 x 0.2 lb/300 kg x 100 g | 21.7 x 16.5" | LCD | lb; oz; lb:oz; kg; g; custom unit | AC/DC | 29.5 x 30 x 9.1" | 71 Lbs |
| Model # | Description | Capacity | Platter Size | Display | Unit of Measure | Battery | Dimensions | Shipping Weight |
|---|---|---|---|---|---|---|---|---|
| D71P10QR5 | Defender 7000 Low Profile Bench Scale | 25 lb x 0.005 lb 10 kg x 0.002 kg | 12 x 12" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 12 x 20.8 in | 36 Lbs |
| D71P15HR5 | Defender 7000 Low Profile Bench Scale | 30lb x 0.005lb 480oz x 0.1oz 30lb : 0.1oz 15kg x 0.002kg 15000g x 2g | 14 x 12" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 14 x 22.8 in | 36 Lbs |
| D71P25QR5 | Defender 7000 Low Profile Bench Scale | 50 lb x 0.01 lb 25 kg x 0.005 kg | 12 x 12" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 12 x 20.8 in | 36 Lbs |
| D71P30HR5 | Defender 7000 Low Profile Bench Scale | 60lb x 0.01lb 960oz x 0.2oz 60lb x 0.2oz 30kg x 0.005kg 30000g x 5g | 14 x 12" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 12 x 3.7 x 14 x 22.8 in | 36 Lbs |
| D71P50QL5 | Defender 7000 Low Profile Bench Scale | 100 lb x 0.02 lb 50 kg x 0.01 kg | 18 x 18" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 31.2 x 23.6 x 9.5 in | 69 Lbs |
| D71P60HR5 | Defender 7000 Low Profile Bench Scale | 150lb x 0.02lb 2400oz x 0.5oz 150lb : 0.5oz 60kg x 0.01kg 60000g x 10g | 14 x 12" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 19.3 x 16.1 x 17.3 in | 36 Lbs |
| D71P60QHL | Defender 7000 Low Profile Bench Scale | 150lb x 0.02lb 2400oz x 0.5oz 150lb : 0.5oz 60kg x 0.01kg 60000g x 10g | 19.7 x 15.7" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 15.7 x 4.1 x 19.7 x 28.5 in | 54 Lbs |
| D71P100QL5 | Defender 7000 Low Profile Bench Scale | 250 lb x 0.05 lb 100 kg x 0.02 kg | 18 x 18" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 18 x 4.5 x 18 x 26.8 in | 69 Lbs |
| D71P150HX5 | Defender 7000 Low Profile Bench Scale | 300lb x 0.05lb 4800oz x 1oz 300lb : 1oz 150kg x 0.02kg 150000g x 20g | 21.7 x 16.5" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 16.5 x 4.9 x 21.7 x 30.5 in | 65 Lbs |
| D71P100HL5 | Defender 7000 Low Profile Bench Scale | 250lb x 0.05lb 4000oz x 1oz 250lb : 1oz 100kg x 0.02kg 100000g x 20g | 19.7 x 15.7" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 15.7 x 4.1 x 19.7 x 28.5 in | 54 Lbs |
| D71P250QX5 | Defender 7000 Low Profile Bench Scale | 500 lb x 0.10 lb 250 kg x 0.05 kg | 24 x 24" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 39.4 x 29.9 x 9.8 in | 95 Lbs |
| D71P300HX5 | Defender 7000 Low Profile Bench Scale | 600lb x 0.1lb 9600oz x 2oz 600lb : 2oz 300kg x 0.05kg 300000g x 50g | 21.7 x 16.5" | LCD | b; oz; lb:oz; kg; g; custom unit | AC/DC | 16.5 x 4.9 x 21.7 x 30.5 in | 65 Lbs |
